Lic. Benito Juárez International Airport, Mexico City, Distrito Federal, Mexico

Location & QuickFacts

Airport Codes	MMMX (ICAO) MEX (IATA)
Location	Mexico City, Distrito Federal, Mexico
Airport Type	A
Longitude/Latitude	N 19° 26' 11.17" / W 099° 04' 18.87" 19.436436, -99.071908
Elevation	7316 feet (2230 meters)
Magnetic Variation	E005447 0408

Communications

Type	Name	Freq 1	Freq 2	Freq 3	Freq 4	Freq 5
Arrival Control	MEXICO ARR	129.6	129.1
Automatic Terminal Information Service	ATIS	127.65
Clearance Delivery	MEXICO CLNC DEL	122.1
Ground Control	GND	121.0	121.85
Radio	MEXICO INFO	126.9
Tower	MEXICO TWR	118.1	118.7

Communication Remarks

• 120.5(E) 129.10(W)

Runway Information

Runway 05L/23R

Dimensions	12,860 x 148 ft (3920 x 45 m)
Surface	Asphalt, asphaltic concrete, tar macadam, or bitumen bound macadam.
PCN	100FDXT

	05L	23R
Heading (Mag/True)	053.0° / 059.0°	233.0° / 239.0°
Latitude	N 19° 25' 39.69"	N 19° 26' 44.63"
Longitude	W 099° 05' 25.13"	W 099° 03' 29.50"
Elevation / TDZE	7316 ft / 7316.0 ft	7316 ft / 7316.0 ft
Displaced Threshold	1458 ft	1686 ft
Slope	0.0°	0.0°
Declared Distances	Takeoff: 13030 ft Landing: 11402 ft	Takeoff: 12860 ft Landing: 11174 ft
Lighting System 1	High Intensity Runway Lights	High Intensity Runway Lights
Lighting System 2	Runway End Identifier Lights	SALS or SALSF
Lighting System 3	Type 50	Type 50

Runway 05R/23L

Dimensions	13,070 x 148 ft (3984 x 45 m)
Surface	Asphalt, asphaltic concrete, tar macadam, or bitumen bound macadam.
PCN	100FDXT

	05R	23L
Heading (Mag/True)	053.0° / 059.0°	233.0° / 239.0°
Latitude	N 19° 25' 37.21"	N 19° 26' 43.12"
Longitude	W 099° 05' 09.19"	W 099° 03' 11.62"
Elevation / TDZE	7316 ft / 7316.0 ft	7316 ft / 7316.0 ft
Displaced Threshold	1491 ft	249 ft
Slope	U°	U°
Declared Distances	Takeoff: 13265 ft Landing: 11579 ft	Takeoff: 13070 ft Landing: 12821 ft
Lighting System 1	High Intensity Runway Lights	High Intensity Runway Lights
Lighting System 2	SALS or SALSF	ALSF-1
Lighting System 3	Type 50	Type 50

Radio Navigation Aids

ID	Type	Name	Freq	Ch	Var
MEX	4	MEXICO	115600M	103X	E005446 0408
MW	5	PLAZA	370000K		E005466 0408
TPX	5	TEPEXPAN	359000K		E005417 0408

Remarks

• [CAUTION]
  Bird haz.
• [FUEL]
  (NC-100LL, A1)
• [RSTD]
  VFR opr by turbojets proh. All US mil acft diverting to this afld must ctc the Defense Attache Office duty officer at the US Embassy Mexico City. Thru ctl agcy call 011-52-555-080-2000. This afld can acpt US mil ldg aft proper coord. Twy
• [RSTD]
  H-1 rstd to wingspan of B-757 or less. Twy A btn Rwy 05R/L clsd when dep/arr Rwy 23R/L. Twy B-4 btn Rwy 05R and Twy E, Twy C-1, Txy C-2, and Twy E btn Twy P-H and A-4 rstd to wingspan less than 118 ft. Acft must be towed onTwy A btn apch
• [RSTD]
  EOR 05R and 05L.
